1 Introduction

This paper integrates a broad research on musical variation intended basically to systematize the analysis of organically-constructed musical pieces. Since 2011 a model for derivative analysis (identified by the acronym MDA) has been developed through the elaboration of original premises, concepts, terminology, and the incorporation of methodological tools and strategies. The practical application of this model in a number of analytical studies since then has led to important improvements and route corrections, aiming the ideals of formalization, efficiency, and comprehensiveness.¹

The research’s main general theoretical framework is centered on the principles of Grundgestalt (normally translated as "basic shape") and developing variation, both created by Arnold Schoenberg, being associated with an organicist conception of musical creation, based on gradual derivation and intense economy of means. These concepts are among the most powerful and far-reaching of Schoenberg's formulations on the compositional domain forming a theoretical complex which has become an important academic subject in the last decades.²

A problematic issue normally faced by analysts is how to describe and label properly processes of developing variation and their outcomes (i.e., the variants created during these processes) in a sufficiently precise, concise, and systematic manner. This difficulty is due mainly to the indefinite ways in which variation techniques can creatively be used by a composer, considering not only “canonic” operations (like inversion, augmentation, etc.), but also hybrid types or even purely idiosyncratic forms of transformation, fruit of contextual situations and of the composer’s own invention. On the other hand, there is a considerable, inherent margin of subjectivity in the task of the interpretation of derivative relations.

The main motivation for the creation of MDA was precisely the search for minimizing the subjectivity of thematic-motivic analysis through the elaboration of a system sufficiently provided of consistent conceptual and methodological tools, in a process that has been gradually consolidated along the last years.

The current version of the model proposes to correlate the notion of variation to some basic principles of the transformational theory. Under this perspective, variation can be considered as a special action which, when applied to a given object (as a musical motive), produces a transformed, but related version of that object. This lies in accordance with Steve Rings, for whom the emphasis in transformations "is on the relationships between musical entities, not on the entities as isolated monads. Transformational theory thematizes such relationships and seeks to sensitize the analyst to them" (RINGS, 2011, p.10, italics in the original).

By exploring this this new approach, I am mainly interested in two aspects: (1) the nature of the relationships between a musical idea of reference and its possible transformed versions (aiming specifically at similarity relations); and (2) the manners in which these transformations can be implemented, which leads to a process of formalization inspired by the ideas of David Lewin (1987) and some of his followers.³

The present paper is focused on the first of these aspects, introducing basic concepts, terminology, and spatial representation, as well as an initial, simple methodological approach for measurement of similarity of musical variants (here limited only to situations with tonal contexts, and compatible cardinalities). More complex alternatives and a detailed discussion about the formal implementation of transformational operations will be addressed in future studies.

2 Basic definitions

A referential musical unity P (stands for "parent") is a short melodic sequence, relatively complete in itself, in which pitch and temporal structures play a special role.⁴ Let these structures be classified as the primary domains of P. The harmonic context (not necessarily tonal) in which P is (explicitly or not) inserted is considered its secondary domain.⁵ Figure 1 presents a simple instance of P (this example will be used as reference along the article).

Figure 1
Figure 1: Example of referential idea P.

In the present context, variation (V) is a generic function that, when applied to P yields a related idea C ("child"), i.e., a (someway) transformed version of P. Let us assume that P and C are two members of the set which contains a conceptually infinite number of possible musical ideas. C is then said as derived from P, or a variant of it, or even that it is a derived idea from the referential P. The adjective "generic" that qualifies the noun "function" in the definition of V reflects both assumptions that P is in some way transformed by the action of V (i.e., it does not matter yet how)⁶ and that C, the output of this transformation, is (also in some way) related to the input P. In other words, V generically represents all possible manners in which P can be transformed into C.⁷ Algebraically, it is then possible to express C in function of P:

The syntactic, ordered interaction of the three elements, P, V, and C will be from now on referred as derivative work.

2.1 Derivative space

A derivative work is basically qualified according to the derivative impact that it causes on the referential idea P.⁸ Alternatively, it is possible to consider the derivative impact directly associated with the amount of similarity/divergence of C in relation to P, which is expressed by the relation of similarity between both musical ideas.⁹ Five basic types are considered:

1. 1. 1. Identity: when C is identical to P (or, in other words, the transformational action of V has no impact in the domains of P);¹⁰

   2. High similarity (or, conversely, low divergence);

   3. Medium similarity (or medium divergence);

   4. Low similarity (or high divergence);

   5. Null similarity (total divergence).

Given this, the action V can be considered as resulting from the opposition of two basic tendencies (or "forces"), intrinsic to the transformational process of P into C: similarity (or coherence, or even invariance) and divergence (or contrast, or variance). The co-relations between them can be viewed as forming a dynamic system, plotted as geometric vectors (Figure 2).

Figure 2
Figure 2: Relation between P and C plotted as a system of vectors.

In this graphical representation of a derivative work, the horizontal, left-to-right axis was arbitrated as corresponding to the dimension of “divergence”, and the vertical, topdown axis to “similarity”.¹¹ P and C are spatially represented by two points situated in the plan and V is a vector that connects them. Thus, V can be decomposed into two orthogonal vector components, Vx (representing "pure" divergence) and Vy ("pure" similarity).

I propose a refinement of this system by establishing a value of 1.00 for both the maximum similarity (or else, identity) and maximum divergence between P and C, resulting in a isosceles-right triangle plotted in a Cartesian plan and defined by the coordinates of its three vertices (see Figure 3): P, representing the referential idea, at the origin (0,0); Q, positioned at the horizontal/divergence limit (1,0); and R, at the vertical/ similarity limit (0,-1). The area delimited by these points is called the derivative space (DS) of the referential idea P.

Figure 3
Figure 3: Derivative space of referential idea P.

As shown in Figure 4, vector V will reach C always on the edge QR in a point (x, x-1).

Figure 4
Figure 4: Derivative space of P, considering a point C positioned on edge QR at coordinates (x, x-1).

Angles α and β are then associated with the derivative impact caused by V in P: the greater is α, the lesser is the divergence between P and C (and, conversely, the greater will be the similarity between them). The opposite applies to angle β. If α = v/4, then |Vy| = 1 and |Vx| = 0 (total divergence, type 5), and if α = 0, then |Vx| = 1 and |Vy| = 0 (identity, type 1). Excluding these extreme cases, any other possible derivative situation (in any combination of similarity/divergence relation), at least conceptually, will lie in a continuum of real values along the edge QR. Figure 5 proposes a segmentation of the derivative space into bands of similarity. Each band is obtained from an angular clockwise increment of v/8 radians (or 22.5 degrees) over the previous one – beginning with the horizontal axis, which represents total divergence/null similarity, and closing with the identity relation (vertical axis).

Figure 5
Figure 5: Representation of the bands of similarity on the derivative space of P.

Table 1 presents the angular limits for the bands of similarity (for practical reasons, I adopt α as main parameter, measured in radians).

Table 1
Table 1: Angular bands for similarity relations in the derivative space of P.

2.1 Attributes

The domains, primary and secondary, are composed by internal, mutually complementary entities, named attributes. Essentially, attributes correspond to abstract descriptors of structural aspects of a musical fragment, and are in MDA formatted as numeric sequences.

The pitch domain has five attributes (Figure 6):

1. p1: pitch sequence, expressed in midi pitches;¹²

2. p2: pitch-class sequence (or p1 under modulo 12);

3. p3: intervallic sequence (the arithmetic differences between contiguous elements of p1);

4. p4: melodic contour (the basic outline of the melody);¹³

5. p5: ambit (the difference between the first and the last element of p1).¹⁴

Figure 6
Figure 6: Pitch attributes of a referential idea P. Angle brackets indicate ordered content. Minus signals preceding integers in p3 and p5 indicate descending intervals.

At first glance, one could consider unnecessary to maintain all five attributes as descriptors of the pitch information, since some of them seem to be mutually redundant (notably p1, p2, and p3). Why not, instead, just to select the most specific, and precise of them, p1, for this purpose? As a matter of fact, however, the five attributes do not describe exactly the same things. The strategy of considering all of them as integrated, correlated descriptors allows for the system to formally capture some subtle transformations between related musical ideas that otherwise would pass unnoticed.¹⁵ The following examples help to clarify this aspect, considering five cases of variants. Three of them (C1, C2, and C3) can be considered as "archetypal variations": change of register, transpositions (chromatic and diatonic), and inversion (Figure 7.).¹⁶

Figure 7
Figure 7: Five pitch variants from P: by octave displacements (C1), chromatic transposition (C2), literal inversion (C3), free change of notes, but keeping the original melodic contour (C4), and free change of contour, but keeping the original ambit.

None of the five variants shares with P the exact content of attribute p1 (mismatches are indicated as underlined numbers). Their relations of similarity with P are though evidenced by other attributes: pitch-class sequence in C1 (a simple case of octave displacement of two events), intervallic configuration¹⁷ in C2 (chromatic transposition to a major third higher), metric contour in C4 (a more distant variation which shares with the referential form only the basic melodic outline), and intervallic ambit in C5 (a still more abstract relation with P, supported just by the maintenance of the distance between initial and final pitch events). On the other hand, C3 has none coincident attribute in relation to P. This suggests mistakenly that is a remote variant, contradicting the general intuition. In the next section I will return to some of these cases, examining them in more details.

The temporal domain is formed by four attributes (Figure 8):¹⁸

1. t1: durational sequence, expressed in multiples of the temporal unity (sixteenth note as default);¹⁹

2. t2: sequence of inter-onset intervals;²⁰

3. t3: metric contour;²¹

4. t4: durational span (the sum of the durations, including eventual internal rests).

Figure 8
Figure 8: Temporal attributes of P.

Figure 9 presents some temporal archetypal variations, demonstrating the importance of taking the four attributes together also in this domain. In the first case, resulted from a simple shortening of some durations, attributes t1 mismatch, but the identity of both t2 and t3 evidence the strong similarity that exist between P and C1. The almost opposite happens with C2, in which the rhythmic configuration is metrically displaced by one quarter note: while t1, t2, and t4 are perfectly preserved, the metric contour is completely modified.²² The last two variants (C3 and C4), in spite of not presenting any matching of the respective four attributes, are very close to P, since they result, respectively, from the canonic operations of augmentation and diminution. In fact, the proximity between variants and the referential unity in both cases is depicted only indirectly, through the relation between the temporal spans (t4): doubled (in C3) and halved (in C4), an aspect that must be taken into account in the calculation of similarity in the temporal domain.

Figure 9
Figure 9: Four archetypal temporal variants from P: by inserting rests among some events (C1), metric displacement (C2), augmentation (C3), and diminution (C4). Mismatches are indicated by underlined numbers, and corresponding attributes are inserted in rectangles.

Harmonic information related to P and C (either explicitly or implicitly) is depicted as an algebraic vector, formed by five attributes:²³

1. h1: referred to the key (expressed as a pitch class);

   h2: referred to mode (by convention, 0 = major mode and 1 = minor mode);

   h3: referred to chordal quality (expressed as a code number between 0 and 9 – see the adopted conventions in Table 2);

   h4: referred to the chordal root (expressed as a pitch class);

   h5: referred to chordal bass (expressed as a pitch class);

The harmonic accompaniment of P (see again Figure 1) is tonally centered in C major. Its first four events are harmonized by a C major triad in first inversion, and the last one by a second-inversion dominant seventh rooted in G. Therefore, there are for P two different harmonic vectors (that incidentally share the same low-level harmonic information, referred to key and mode), the first one associated with events 1 to 4 (labeled as h_1-4) and the second with event 5 (h₅). They are formatted as follows: h1-4 = <0, 0, 0, 0, 4> (to be read as “first-inversion of C major triad inside the key of C major”).

h₅ = <0, 0, 4, 7, 2> (to be read as “second-inversion of G7 chord inside the key of C major”).

As done previously for the primary domains of pitch and time, Figure 10 shows four cases of archetypal harmonic variations (I am assuming here that the key signatures of the examples unambiguously inform their respective tonal contexts): chromatic modulation (C1); diatonic chordal change (C2), with the substitution of C major triad (contextualized as the tonic I) by E minor triad (iii); modal interchange (C3); and a simple inversion of the original chord (C4). Each situation presents a different configuration of the harmonic vector.

Figure 10
Figure 10: Four archetypal harmonic variants from P: chromatic modulation (C1), diatonic chordal change (C2), mode interchange (C3), and inversion (C4). Mismatches are indicated by underlined numbers.

The multidimensional nature of a musical idea, expressed by the set of domains/ attributes, can be better displayed in the format of a matrix (identified with the letter M). While the number of rows of M is fixed in twelve (corresponding to the complete set of attributes, encompassing primary and secondary domains), the number of columns varies according to the total of events present in the referential idea.²⁵ The first four rows are related to the pitch domain: p1, p2, and p4 occupy respectively rows 1, 2, and 4. Since p3 is a sequence of differences between pitches, it always has one element less than p1, p2, and p4. So, by convention, it is positioned in the third row, with the ambit (p5), formed by a unique element, occupying the last cell.²⁶ The following three rows refer to the temporal domain, t1, (t2 + t4), and t3. The third section of M (rows 8-12), related to the harmonic domain, is filled rather vertically than horizontally, according to the correspondences between events and harmonic contexts. Figure 11 depicts the structure of the matrix of attributes of the referential idea P.

Figure 11
Figure 11: Structure of the matrix of attributes of P.

A matrix of attributes can then be considered as an algebraic equivalent of a given musical idea which it is related to (at least concerning pitch, temporal, and harmonic information).

3 Measurement of similarity

An important aspect of MDA is the possibility of measurement of similarity between referential and derived ideas. This is systematically accomplished through the interaction of concepts and premises that were so far introduced, in combination with the treatment for similarity evaluation that is proposed in the book The Geometry ofMusical Rhythm, by Gottfried Toussaint (2013). In his chapter 33, Toussaint subdivides the methods for measurement of similarity between objects (not necessarily musical ones) into two basic categories:

feature-based methods and transformation-based methods. In feature-based methods, objects are compared in terms of the number of traits they have in common. In transformation-based approaches, similarity is measured by how little effort is required to transform one object to another. (TOUSSAINT, 2013, p.249, italics in the original).

Touissant then describes five transformational approaches, commenting their advantages under the standpoint of his objectives: Hamming distance, swap distance, directed-swap distance, many-to-many assignment distance, and edit distance. Because he is especially interested in comparing rhythms with either equal or different numbers of onsets and/or pulses (that is, with different cardinalities, according to the present terminology), his focus is concentrated on the most robust of them, the edit distance ap- proach, also called Levenshtein distance.²⁷ Basically, this method counts "the minimum number of edits (or mutations) necessary to convert one sequence to the other" (TOUSSAINT, 2013, p.252, italics in the original).²⁸ Three types of operations are considered: insertion, deletion, and substitution. Toussaint exemplifies the application of the method in the transformation of the word "WAITER" into "WINE", which have different "cardinal- ities" (respectively, 6 and 4). The process involves two stages: (1) deletion of letters "A" and "R": "WAITER" → "WITE"; and (2) substitution of "T" by "N": "WITE" → "WINE".²⁹ Figure 12 proposes a graphic representation of this example, adapted to the MDA’s terminology.

Figure 12
Figure 12: Representation of edit-distance method, after TOUSSAINT (2013, p.252).

Due to a strong alliance of simplicity and efficiency, the edit distance is an ideal candidate for measurement of similarity between two related musical ideas in MDA. I adopt here a somewhat modified version of the method, adapting it in order to deal with the structural particularities of the matrix of attributes. Considering a referential unity P and a possible variant of it, C, our adapted edition-distance approach basically counts the number of editions which are necessary to transform the matrix of attributes of P into the matrix of attributes of C. However, there is an important difference in relation to Toussaint's description: since the matrices are multidimensional structures, involving musical attributes of distinct natures and meanings, the editions will be differently weighted, depending on the rows considered (this will be detailed in the due time). In the present article I will consider uniquely the simplest situation of derivative work, namely when P and C have the same cardinality.³⁰

3.1 General information

Assuming that P and C have compatible cardinalities, the transformational types “deletion” and “insertion” are here out of question: only substitutions are applied in the mapping of P into C. In other words, the elements present in P's and C's matrices are always one-to-one related, and the “distance” between two corresponding elements will be measured as the “interval” (broadly, in David Lewin’s sense) between them.31 Figure 13 presents a general idea of the method. Since the number of events of P and C is necessarily the same, their matrices of attributes are also equally formatted (say, with m rows and n columns). This means that a given element of the matrix of P (Pi,j) will be related to one of the matrix of C positioned at same coordinates (Ci,j) and the “distance” between them (δ) will be proportionally equivalent to the abstract difference of their contents. Thus, δ will be null if both elements are equal (implying total similarity in the respective locus), and will have any positive value (depending on the magnitude of the interval) if they are different. As a convention aiming at a rapid visualization, let us indicate non-equal elements in C inside gray cells, as depicted in Figure 13 (this will be used in further examples).

Figure 13
Figure 13: General scheme of measurement of similarity between elements of P and C.

A necessary function of the algorithm for measurement of similarity of P and C is to establish distinct weights for the differences between elements, according to the relevance of the musical descriptors associated. Not surprisingly, the assignment of weights is decisive aspect of the algorithm but, at the same time, a considerably complex task involving multiple possibilities. In fact, the values that will be here adopted result from a relatively long empirical process, combining the try-and-error method with a number of intuitive assumptions.

Aiming the simplification of the process, the matrices are subdivided into sections associated with the three domains, pitch, time, and harmony, and will be examined separately.

3.2 Measurement of similarity in the pitch domain

Initially, it is necessary to delimit the section of the respective matrices of attributes that will be worked out. Thus, define Pp and Cp as sub-matrices corresponding to the first four rows of the matrices of attributes, referential (P) and variant (C). Let us generically identify these structures as matrices of pitch attributes.

The similarity between Pp and Cp is measured considering five vectors, each one associated with one of the five attributes:

• v1: vector associated with the pitch sequence (p1);

  v2: vector associated with the pitch-class sequence (p2);

  v3: vector associated with the intervallic sequence (p3 or d-p3);

  v4: vector associated with the melodic contour (p4);

  v5: vector associated with the ambit (p5);

Vectors v1, v2, v3, and v4 have n elements, corresponding to the cardinality of Pp and Cp. Vector v5 is in fact a scalar, since it is always formed by a single element. The obtaining of the five vectors proceeds in a similar manner, but with some particular differences, as follows:

• • Vector v1 results from the absolute difference between the first row of Cp and Pp. Formally,

  v1 = |Cp(1, :) – Pp(1, :)|

  • Vector v2 results from the absolute difference between the second row of Cp and Pp, considering the operation of modulo 12. Formally,

  v2 = |mod12(Cp(2, :) – Pp(2, :))|

  • Vector v3 results from the absolute difference between the third row of Cp and Pp, disregarding the respective last elements (since they are related to ambit, p5). Formally,

  v3 = |Cp(3, 1:end–1) – Pp(3, 1:end–1)|

  • Vector v4 results from the absolute difference between the fourth row of Cp and Pp. Formally,

  v4 = |Cp(4, :) – Pp(4, :)|

  • Vector v5 results from the absolute difference between the last element of the third row of Cp and Pp . Formally,

  v5 = | Cp(3, end) – Pp(3, end)|

After this, a five-element related structure, called pitch vector (vp), is created from the ordered sum of the elements of v1 to v4, followed by v5, such that

vp = sum(v2), sum(v3), sum(v4), v5>

The five elements of vp are then assigned to weights, which are organized also as a five-entry vector (wp), such that

wp = <15, 15, 40, 25, 5>

This hierarchical disposition of values (as said above, obtained after empirical attempts) reflects the intuition that the intervallic organization of a musical motive plays a more decisive role in the characterization of its pitch structure. The abstract melodic contour occupies a second place, followed by pitch and pitch-class sequences, with the ambit becoming the lesser influence of the descriptors.

A definitive index representing the edition-distance in the pitch domain is then calculated as the dot product³² of vectors vp and wp. Let us call this index a (provisional) pitch penalty (labeled as kp’), which is intended to express the degree of dissimilarity between P and C in the isolated domain of pitch. Formally,

Equation 2
Equation 2: Provisional pitch penalty.

As a final measure, kp’ shall be normalized inside values 0.00 (referring to maximal similarity) and 1.00 (representing maximal dissimilarity), in order to provide both coherence and standardization to the system, considering that analogous penalties will be also assigned to the temporal and harmonic domains. The normalized pitch penalty (kp) is obtained from the formula

Equation 3
Equation 3: Normalized pitch penalty (first version).

Where kp’ is the provisional pitch penalty, kp_min and kp_max are, respectively, the minimal and maximal pitch penalties. Assuming kpmin = 0.00, Equation 3 is reduced to

Equation 4
Equation 4: Normalized pitch penalty (concise version).

While it is almost trivial to establish a relation of maximal similarity between two objects (formalized in the present proposal when the matrix of pitch attributes of C is a copy of that of P), the determination of a "maximally contrasting" structure in relation to a referential one is a considerably problematic task. Obviously, contrast is not an absolute quality. Likewise, the idea of a clear-cut border separating similar objects from entirely dissimilar ones is almost nonsense. As a matter of fact, we can talk about (conceptually) infinite possibilities for contrasting motives, in also infinite gradations of dissimilarity. From this, it is easy to conclude that many and many objects can be considered as perfectly contrasting in relation to a given reference. In other words, the pitch configuration we need as “maximally” dissimilar for the normalization process can be realized in any way provided it contrasts sufficiently in respect to the referential material.³³ Given this, Figure 14 proposes a possible "maximally-contrasting" pitch configuration related to the musical idea of Figure 1, depicting also the stages for calculation of the pitch penalty, in this case corresponding to a maximum value (labeled, therefore, as kp_max). Since only the domain of pitch is here in question, both ideas are musically notated as open-headed notes, disregarding their respective rhythmic-metric contexts. The figure also depicts the calculation of pitch penalty.

Figure 14
Figure 14: Two contrasting pitch configurations, used for the calculation of a possible maximal pitch penalty (kpmax).

The algorithm can be tested now with three of the cases of archetypal variation of pitch domain presented in Figure 7: C1, C2, and C5. Let label the first variant of Pp as C1p, reproduced in Figure 15 as a pitch abstraction.

Figure 15
Figure 15: Calculation of pitch penalty in the comparison between Pp and C1p.

Before continuing, some reflection shall be made considering the particularity of this case. As previously introduced, this variant was created by simple changing of register of two pitches of Pp: the second one (E4), sent an octave higher to E5, and the fourth (A4), transposed an octave lower to A3. Intuitively, these are very superficial transformations, an assumption that is perfectly captured by the null values of v2 (which deals with pitch classes). However, these simple changes disturb profoundly the intervallic vector, v3, which is incidentally the most weighted in the algorithm, resulting into a disproportionally high penalty, distorting the perception of similarity between referential and variant ideas. This leads to an adjustment of the algorithm, in order to enable it to treat similar situations in a more realistic manner. It is formulated as a rule (other similar rules will be eventually added in further stages):

Adjustment rule #1 (pitch domain): Any “12” inside v3 shall be reduced to one third (i.e., to “4”).³⁴ Formally,

if v3 = <x, y, …, 12, …, z>, then v3 = <x, y, …, 4, …, z>.

The application of rule #1 in the calculation of the pitch penalty for C1p results into a more appropriate, lower value: kp = 0.28.

The second variant C2p results from a chromatic transposition of Pp by four ascending semitones, as shown in Figure 16). Accordingly, only the original pitch and pitch-class sequences are transformed.

Figure 16
Figure 16: Calculation of pitch penalty in the comparison between Pp and C2p.

In spite of the lower value obtained for kp (corresponding to the intuition that both ideas are closely related), another adjustment in the algorithm becomes necessary, preventing from eventual incoherence. Such argument can be easily understood if we consider that chromatic transpositions by different number of semitones will produce (in some cases, sharply) different values of penalties, when the algorithm is applied. This goes against the scientific knowledge³⁵ that argues that distinct levels of transposition should affect equality (and in a very low rate) the evaluation of similarity. As an illustration of this distortion, consider two different ascending-chromatic transpositions of Pp, by one and nine semitones. The application of the algorithm in both cases will result for kp, respectively, 0.04 and 0.33, a difference of more than 1000%. Given this, a new adjustment rule must be proposed:

Adjustment rule #2 (pitch domain): If v1 and v2 are formed by the replication of a unique number, substitute its eventual occurrences by “2” (in both vectors), not mattering the magnitude of the original number. Formally,

if v1 = <x, x, …, x> and v2 = <y, y, …, y>, then v1 = v2 = <2, 2, …, 2>

In the case of C2p, since v1 = <4, 4, 4, 4, 4>, it shall be replaced by v1 = <2, 2, 2, 2, 2>, just like v2 (this procedure will be adopted from now on for any possible transposition, that become, therefore, completely equivalent). Consequently, the pitch penalty of C2p is updated to 0.07.

Lastly, Figure 17 depicts the calculation of pitch penalty for C5p, which keeps only the ambit as common attribute with the referential material.

Figure 17
Figure 17: Calculation of pitch penalty in the comparison between Pp and C5p.

3.3 Measurement of similarity in the temporal domain

Taken as basis the edition-distance method elaborated for evaluating the pitch structure, a similar algorithm was elaborated for the temporal domain. Firstly, define the sections of the matrices of attributes of both P and C which will be considered, namely, limited by rows 5 to 7. Name these sections as, respectively, Pt (or the matrix of temporal attributes of P) and Ct (or the matrix of temporal attributes of C). Now, define four difference vectors:

• v1: associated with the durational sequence (t1), v1 = |Ct(1, :) – Pt(1, :)|;

  v2: associated with the IOI sequence (t2), v2 = Ct(2, 1: end–1) – Pt(2, 1: end–1);

  v3: associated with the metric contour (t3), v3 = |Ct(3, :) – Pt(3, :)|;

  v4: associated with the temporal span (t4), v4 = |Ct(2, end) – Pt(2, end)|.

As done before, the entries of the vectors v1 to v3 are summed and the results, together with the scalar v4, are ordered into a structure called temporal vector (vt), such that

vt = <sum(v1), sum(v2), sum(v3), v4>

A four-entry vector of weights, calibrated for the temporal characteristics is then established as

wt = <15 45 30 10>

This reflects the intuition that the intervals between onsets (IOIs) are the most decisive factor in the definition of a rhythm, followed by its metric localization. According to the current conception, duration and temporal span are only secondary descriptors. Like the case of pitch, a provisional penalty for temporal domain (denoted as kt’) is calculated as the dot product of vt and wt. And once again, for a matter of coherence, kt’ must be normalized, which requires a minimal and maximal value for temporal penalty. Since ktmin (corresponding to an exact copy of a rhythmic configuration) can be settled as convention to zero, the normalized temporal penalty (kt) will result from the division of kt’ and a (possible) maximal value (kt_max). As discussed in the last section, since the process of measurement of similarity involves always objects which are someway related, for this purpose it would suffice only to conceive a rhythmic configuration profoundly contrasting in relation to Pt (among many possible alternatives), as that depicted in Figure 18.

Figure 18
Figure 18: Two contrasting temporal configurations, used for the calculation of a possible maximal temporal penalty (ktmax).

As a test for the algorithm for measuring temporal similarity I select the second and the third of the four variants introduced in Figure 9 (here denoted as C2t and C3t).

Variant C2t is a perfect copy of Pt, only metrically dislocated by one eight-note (Figure 19). However, this simple transformation is responsible for a establishing a medium dissimilarity in relation to Pt, evidencing the decisive importance of meter in rhythmic characterization.

Figure 19
Figure 19: Calculation of pitch penalty in the comparison between Pt and C2t.

Variant C3t, compared to Pt in Figure 20, presents an exact duplication of the original durations (an augmentation in compositional jargon). The high value obtained for penalty is quite counter-intuitive, since in this case durational and IOI proportions are kept unaltered. Indeed, the parenthood between a given rhythmic configuration and its augmented version (the same would be applicable to the reverse case, i.e., diminution) is easily perceived, everything else being constant. A third point of interest concerns the odd discrepancy between the metric contours of Pt and C3t, also contrary what would be expected (since durational proportions are strictly maintained).

Figure 20
Figure 20: Calculation of pitch penalty in the comparison between Pt and C3t.

Let us examine firstly this last issue. As a matter of fact, the discrepancy of C3t's metric contour is only apparent: because the durations were duplicated, it would be also necessary to consider the duplication of the metric contour, in other words, treat the variant in hypermetrical terms.³⁶ That is, the segment shall be considered as a unity, in this case formed by two 4/4 measures (or, alternatively, one 8/4 measure). From this, the metric contour of C3t should be rewritten as <41302>, thus mapping the original contour. This obviously impacts the calculation of the corresponding temporal penalty, which is then updated: kt ≈ 0.82.

Allying this to the question of the high (and discrepant) values of dissimilarity of both variants, a new adjustment rule (with three stages) must be formulated, in order to improve the algorithm.

Adjustment rule #3 (temporal domain): If the division of the elements of row Pt(1, :) by the corresponding elements of row Ct(1, :) results into a replicated number x (normally x = 2 or ½), then

(a) set all values of v1 and v2 to "1". Formally,

if <Pt(1, 1) / Ct(1, 1), Pt(1, 2) / Ct(1, 2), …, Pt(1, n) / Ct(1, n)> = <x, x, …, x>, then v1 = v2 = <1, 1, …, 1>.

(b) replace v3 with the content of row Pt(3, :). Formally,

v3 = Pt(3, :).

(c) set v4 to "½".

Applying this rule to the algorithm, the penalties of C3t is recalculated to a more realistic value: kt ≈0.23.

3.4 Measurement of similarity in the harmonic domain

Due to the particular structure of the harmonic section of the matrix of attributes, the algorithm for measurement of harmonic similarity between two musical ideas presents some differences in relation to those constructed for pitch and time. Firstly, there is just one vector (and not five or four, as in the pitch and temporal domains), called harmonic vector (vh), designed to measure “distances” between attributes of parent and child. Moreover, contrarily to those, it does not express numeric differences, but rather relations of congruence and divergence between harmonies, by the use of binary notation (1 = divergence / 0 = congruence) and mapping any entry of vh to one harmonic attribute (i.e., h1 to h5). In this manner, a perfect copy of a harmonic context would be represented by vector vh = <0, 0, 0, 0, 0>.

Let the vector of harmonic weights be formatted as³⁷

wh = <45, 25, 15, 10, 5>

As done before, the provisional harmonic penalty (kp’) is calculated as the dot product of vh and wh. Likewise, the normalized harmonic penalty (kp) is equal to the division of kh’ by the maximal possible harmonic penalty (kh_max). However, contrarily to what was applied to the other algorithms, since vh is a binary vector, it is not necessary to elaborate a hypothetical contrasting example for the calculation of kh_max, considering that a maximally-divergent harmony will be obligatorily expressed as vh = <1, 1, 1, 1, 1>. Consequently, kh_max = <1, 1, 1, 1, 1> . <45, 25, 15, 10, 5> = 45 + 25 + 10 + 5 = 100.

Let us now test the algorithm with the isolated harmonic variants presented in Figure 10, reproduced in Figure 21 with the calculation of the respective harmonic penalties.

Figure 21
Figure 21: Calculation of harmonic penalties in the comparison between Ph and C1h, C2h, C3h, and C4h.

Another difference in relation to the remaining algorithms concerns the fact that commonly more than one event of a given musical idea has the same harmonic context (as in the case of Figure 1). This means that a replicated harmonic context in, say four events, will necessarily replicate the harmonic penalty four times. In fact, the harmonic penalty for a musical idea as a whole will then be calculated as the arithmetic mean of the individual penalties.³⁸

3.5 Global similarity between musical ideas

After obtaining the penalties concerned to the three individual domains by the respective algorithms, a global measure of the dissimilarity k between two related musical ideas can be yielded. This is made through a weighted combination of the three values (kp, kt, and kh), as disposed in Equation 5. The distribution of weights attempts to capture two intuitions: firstly, the strong prominence of the primary domains (pitch and time) in face of the secondary harmony (85% vs 15%), and secondarily, the relative greater permeability of pitch structures to variation in comparison with rhythmic/metric configurations.³⁹

Equation 5
Equation 5: Global penalty for dissimilarity.

Three examples will provide adequate understanding of the process of determination of a global penalty in real musical situations. Figure 22 presents three possible variants of a referential idea P, considering transformations that affect indistinctly elements of the pitch, temporal, and harmonic domains.

Figure 22
Figure 22: Three possible variants of P.

The cases can be informally described as follows:

1. C1 – presents slight modifications in pitch and temporal structures. A secondary dominant (V/V, chord label D7) is inserted as preparation for the last chord;

   C2 – the rhythmic configuration of P is preserved, but the melodic arc is freely expanded, with the harmony transposed to D minor;

   C3 – here a more substantial modification is in the temporal structure. The penultimate pitch is chromatically flexed. The harmonic context is kept unaltered.

The next three figures compares P with the variants, depicting also for each case the respective individual and global penalties (for practical reasons, it is assumed that the process was now computationally automatized; therefore, only the final results are provided, omitting all subjacent calculations).

Figure 23
Figure 23: Determination of global penalty for variant C1.

Figure 24
Figure 24: Determination of global penalty for variant C2.

Figure 25
Figure 25: Determination of global penalty for variant C3.

Table 3 shows the penalties assigned to the three variants.

3.5 Spatial representation of similarity relations

With these data and recalling to the derivative space's model of section 2.1, it is also possible to plot similarity relations between musical ideas, a very attractive perspective to be developed in the future with analytical purposes. Figure 26 reproduces the graph of the Figure 4, substituting the variable x by the penalty for dissimilarity k.

Figure 26
Figure 26: Model of derivative space (adapting Figure 4).

For this, the calculated penalty value is associated with the horizontal projection (now expressing coordinate k) of point C.⁴⁰ Since the vertical projection is function of k (i.e., f(k) = k – 1), point C’s coordinates are then properly established. The angle →, which is related to what I will call the derivative inclination of point C, is easily obtained through trigonometry (Equation 6):₄₁

Equation 6
Equation 6: Angle α in function of k.

Table 4 updates Table 3, by including the variants’ coordinates, angles’ values (in degrees), and respective degrees of similarity.

The plotting of the three points in the derivative space of P is depicted in Figure 27.

Figure 27
Figure 27: Points C1-3 plotted in the derivative space of P.

Concluding remarks

This article introduced an original conception addressing systematical analysis of musical variation under a transformational approach, and isolated from any temporal/ contextual perspective. Basic concepts and methodological procedures presented in the study focused on the nature of the relationships between referential and derived ideas. The notions of domains and attributes made possible the elaboration of algorithms for quantification of similarity relations, through calculation of specific penalties, which in turn were used for graphical representation of these relations, plotted on the derivative space of the referential idea. It is noteworthy to add that the system has a great potential for computational implementation, leading to automatization of the processes of calculation of penalties and plotting of similarity relationships.

As previously stated, the essential goal of the present paper is to introduce a new version of the analytical model, considering exclusively its most basic elements and some simple analytical applications. More complex situations (like non-tonal contexts and comparison of structures with different cardinalities) will be properly examined in future studies. An approach addressing the specific manifestations of function V, formally denoted as transformational operations, is described in a recently published article (ALMADA, 2019), which complements the present study.

The investigation of variation across time (that is, contextualized), deeply grounded on Schoenbergian principles of developing variation and Grundgestalt and involving proper theoretical/methodological apparatus, represents the natural continuation of the research, which is intended to provide the model of a comprehensive and dynamic perspective concerning real-music situations.

References

ALMADA, Carlos (2019). Variation and Developing Variation under a Transformational Perspective. Musica Theorica, v.4, n.1, p.30-61.

ALMADA, Carlos (2017). Gödel-vector and Gödel-address as tools for genealogical determination of genetically-produced musical variants. In: The Musical-Mathematical Mind: Patterns and Transformations. Cham (Switzerland): Springer Verlag, p.9-16.

ALMADA, Carlos (2016). Derivative Analysis and Serial Music: the Theme of Schoenberg’s Orchestral Variations Op.31. Per Musi, v. 33, p.1-24.

ALMADA, Carlos (2015). Evolution in Musical Contexts: The Software DARWIN. In: XXV ENCONTRO ANUAL DA ANPPOM, 2015. Vitória. Anais ... Vitória: UFES.

ALMADA, Carlos (2013). Considerações sobre a análise de Grundgestalt: aplicada à música popular. Per Musi, n. 29, p. 117-124.

ALMADA, Carlos (2011). A variação progressiva aplicada na geração de ideias temáticas. In: II SIMPÓSIO INTERNACIONAL DE MUSICOLOGIA. Anais ... Rio de Janeiro: UFRJ, 2011. p.79-90.

AUERBACH, Brent (2005). The Analytical Grundgestalt: A New Model and Methodology Based on the Music of Johannes Brahms. Thesis (PhD in Music). University of Rochester.

BOSS, Jack (1992). Schoenberg's Op. 22 Radio Talk and Developing Variation in Atonal Music. Music Theory Spectrum, 14/2, pp. 125-149.

CARPENTER, Patricia (1983). Grundgestalt as tonal function. Music Theory Spectrum, 5, pp. 15-38.

COLLISON, Stephen (1994). Grundgestalt, Developing Variation, and Motivic Processes in the Music of Arnold Schoenberg: An Analytical Study of the String Quartets. Thesis (PhD in Music). King’s College.

DOWLING, Jay (1978). Scales and Contour: Two Components of a Theory of Memory for Melodies. Psychological Review, 85/4, pp.341-354.

EPSTEIN, David (1980). Beyond Orpheus: Studies in music structure. Cambridge: The MIT Press.

FRISCH, Walter (1984). Brahms and the Principle of Developing Variation. Los Angeles: University of California Press.

GOLLIN, Edward (2000). Representations of Space and Conceptions of Distance in Transformational Music Theories. Thesis (PhD in Music). Harvard University.

HAIMO, Ethan (1997). Developing Variation and Schoenberg’s Serial Music. Musical Analysis, 16/3, pp. 349-365.

HAIMO, Ethan (1990). Schoenberg’s Serial Odyssey: The Evolution of His Twelve- Tone Method 1914-1928. Oxford: Clarendon Press.

HOSKINSON, Darin (2006). The Grundgestalt and Network Transformations in the Late Choral Works of Anton Webern. Thesis (PhD in Music). University of Oregon.

HURON, David. Voice Leading: The Science Behind a Musical Art. Cambridge: The MIT Press, 2016.

HURON, David. (2006). Sweet Anticipation: Music and the Psychology of Expectation. Cambridge: The MIT Press.

LEWIN, David (1987). Generalized Musical Intervals and Transformations. New Haven: Yale University Press.

MAYR, Desirée (2018). The Identification of Developing Variation in Johannes Brahms Op.78 and Leopoldo Miguéz Op.14 Violin Sonatas through Derivative Analysis. 2018. These (Doutorado em Música) – Universidade Federal do Rio de Janeiro.

MAYR, Desirée; ALMADA, Carlos (2017a). Geometrical and Vector Representation of Metrical Relations. In: II CONGRESSO DA ASSOCIAÇÃO NACIONAL DE TEORIA E ANÁLISE MUSICAL, 2017. Florianópolis. Anais ... Florianópolis: UDESC, p.10-19.

MAYR, Desirée; ALMADA, Carlos (2017b). Correlations between Developing Variation and Genetic Processes in the Analysis of Brahms' Violin Sonata Op.78. In: IX EUROPEAN CONGRESS OF MUSICAL ANALYSIS, (9.), 2017, Strasbourg. Proceedings... Strasbourg: EUROMAC (extended abstract).

MAYR, Desirée; ALMADA, Carlos (2016). Use of Linkage Technique in Johannes Brahms’ Op.78 and Leopoldo Miguéz’s Op.14 Violin Sonatas. Opus, v. 22, n. 2, p. 429-449.

McADAMS, Stephen & MATZKIN, Daniel (2001). Similarity, Invariance, and Musical Variation. In: Annals of the New York Academy of Sciences. Vol. 930: The Biological Foundations of Music, pp. 62-76.

MEYER, Leonard (1989). Style and Music. Chicago: The University of Chicago Press.

MORRIS, Robert (1987). Composition with Pitch-Classes: A Theory of Compositional Design. New Haven: Yale University Press.

NEFF, Severine (1984). Aspects of Grundgestalt in Schoenberg’s First String Quartet, Op.7. Journal of the Music Theory Society, 9/1-2, pp.7-56.

NG, Yuet (2005). A Grundgestalt Interpretation of Metric Dissonance in the Music of Brahms. Thesis (PhD in Music). Eastman School of Music, University of Rochester.

RINGS, Steve (2011). Tonality and Transformation. Oxford: Oxford University Press.

RUFER, Joseph (1954). Composition with Twelve Notes. (Humphrey Searle, trad.). London: Rocklife.

SCHIANO, Michael (1992). Arnold Schoenberg's Grundgestalt and its Influence. Thesis (PhD in Music). Brandeis University.

SCHOENBERG, Arnold (1984). Style and Idea: Selected Writings of Arnold Schoenberg. London: Faber & Faber.

TEMPERLEY, David (2001). The Cognition of Basic Musical Structures. Cambridge: The MIT Press.

TOUSSAINT, Gottfried (2013). The Geometry of Musical Rhythm: What Makes a "Good" Rhythm Good? Boca Raton: CRC Press.

Notes
