Introducción

Chagas disease, also called American Trypanosomiasis, is a disease caused by the protozoan parasite Trypanosoma cruzi. The World Health Organisation (WHO) estimates that there are between 6 and 7 million people infected by Trypanosoma cruzi, which causes Chagas disease, in 21 countries of the American continent, meaning that approximately 13% of the Latin American population is at risk of contracting the disease². Bolivia, in this context, suffers one of the highest infection rates of Chagas disease with a seroprevalence of more than 50%³. This disease was established almost exclusively in rural areas. Currently, because of population migrations, not only from rural areas but also across continents, there has been a change in the epidemiological profile of Chagas disease^-6. The World Health Organisation’s report on Leishmaniasis indicates that there are about 1,500,000 people affected by various forms of the disease worldwide. It is estimated that around 350 million people are at risk of infection and illness each^7-9. In Bolivia, Leishmaniasis is less common than Chagas disease, but it affects people in five of Bolivia’s nine departments¹⁰.

In different regions of Latin America, T.cruzi and Leishmania infection overlap^10-12. This is the case in some regions of Brazil, the Yungas in Bolivia and northern Argentina, where both infections coexist^10,14. Previous reports indicate the existence of mixed circulating infections in both reservoirs and humans, with the presence of overlapping ecological niches of T. cruzi and Leishmaniasis.^10,14, causing the development of mixed infections, which is why conventional diagnostic tests should be applied with caution as they can be cross-reactive¹⁴. Hence the importance of performing different serological tests such as ELISA, HAI and specific IF for the diagnosis of the chronic phase of Chagas disease and smear and/or culture for the diagnosis of American tegumentary Leishmaniasis¹⁵. For the serological diagnosis of Leishmaniasis and Chagas disease, Indirect Immunofluorescence (IIF) was usually performed. This is a relatively low-cost technique due to the fact that the antigenic substrate can be prepared in any medium-complex laboratory¹⁶, furthermore, this technique has a very good diagnostic sensitivity and specificity, particularly for Chagas disease¹⁷. However, the use of this serological technique for the diagnosis of Leishmaniasis is currently in doubt, as experts do not recommend the use of IF when Chagas disease and Leishmaniasis are both present^15,18, especially in tropical and subtropical regions because of possible cross-reactions between the two pathologies at low titres, given that the aetiological agents of these two diseases have a very close common ancestry^19,20, therefore, it is to be expected that they share a significant number of antigenic characteristics. Thus, patients with either infection or mixed infection may be misdiagnosed as a result of serological cross-reactions when mixtures of uncharacterised antigens are used^21,22.

Given the need to differentiate between these two pathologies in a tropical region of the department of Cochabamba, where both pathologies are found, because of the population migration flows in recent years from Chagas endemic areas to tropical regions endemic for Leishmaniasis, this descriptive study was carried out to determine the differential diagnosis of Leishmaniasis, Chagas disease and mixed infection using T. cruzi epimastigotes (autochthonous TcV) following the technique of Luis Vásquez Huerta et al¹⁶.

Materials and methods

Ninety-seven blood serum samples belonging to people with absence of Chagas disease and/or Leishmaniasis infection and people infected with T. cruzi and Leishmania spp. were studied, arranged as follows: Serum samples from patients with Leishmania spp Infection (n=23), Serum samples from patients with mixed Leishmania spp and T. cruzi Infection (n=11), Samples with T. cruzi Infection (n= 30) and Serum samples from patients with no evidence of both infections (n= 33).

Said panels were prepared from samples collected at the immunology laboratory of the LABIMED service and the laboratory of the San Francisco de Asís hospital in the municipality of Villa Tunari.

The serum panels were organised into four groups (A, B, C, D), summarised in table 1, making a total of 97 samples obtained.

Analytical procedures

a. Obtaining T. cruzi epimastigotes

Trypanosoma cruzi (TcV) parasites in their epimastigote form were donated by Dr. MC Torrico, which were obtained from cultures in the Parasitology laboratory of the LABIMED service, Faculty of Medicine, Universidad Mayor de San Simón.

b. Indirect immunofluorescence (IFI)

For the Indirect Immunofluorescence technique (IF), a positive control and a negative control were used. The antigen used was Trypanosome epimastigotes obtained from cultures (Donation), which were fixed on slides and preserved in the freezer. The antigen-antibody reaction was performed on these slides.

In a microtitre plate, 1/16, 1/32 and 1/64 dilutions of each serum to be evaluated and of the controls were made. Once homogenised, these were dispensed in the area of the circle corresponding to the plate. Once the plate was incubated, washed with PBS-Tween and dried, 15 uL of fluorescein-labelled anti-human IgG conjugate (Biomerieux) was added, incubated for 30 minutes, the slides were washed again and left to dry for the readings.

c. Immunofluorescence microscopy observation

During the observation of the samples, emphasis was placed on the intensity, presence and absence of fluorescence on the surface and nucleus of the epimastigotes. Readings were recorded as: Positive for Chagas(+). When the surface or edges of the parasites fluoresced a deep apple-green colour. Positive for Leishmania. Recorded, when the core of the parasites fluoresced a deep apple-green colour, according to ref16.

Mixed: when the surface and nucleus both fluoresced bright green; Negative (-) If the parasites appear dull and dark and finally Indeterminate (I) If a faint inhomogeneous fluorescence is observed on either the surface or nucleus of the parasites.

d. HAI technique for Chagas

For indirect haemagglutination, the HAI Chagas Polychaco kit which employs ram red blood cells was used. The dilution with which the procedure was started was 1/8, for which in a microtitre plate 70 μL of the serum diluent was placed in the first wells and 25 μL of diluent in the second, third and fourth wells. To the first wells, 10 μL of the Serum to be evaluated were also placed, in addition to the positive and negative control Serum. Se realizó diluciones sucesivas transfiriendo 25 uL de los sueros a evaluar, desde la dilución 1/8 hasta el 1/64, desechando los últimos 25uL. Subsequently, 25uL of the antigen suspension was added to each well. The plate was stirred and allowed to settle for 60 minutes until it was ready for reading.

Statistical analysis

The statistical analysis of the results was carried out using Frequency Distributions. Ethical considerations Permission was obtained from patients for the collection of blood samples for the purpose of this study in both laboratories.

Results

The blood serum panels (Table 1) represent subjects with defined diagnostic characteristics.

The samples included in panel A, corresponding to 23 individuals, were identified as Leishmania spp infection based on clinical and laboratory diagnostic results. The samples in panel B belonged to 11 subjects with mixed infection by Leishmania spp and T. cruzi, based on the laboratory diagnostic results. Likewise, the samples included in panel C corresponded to 30 people with Trypanozoma cruzi infection. Finally, the samples in panel D belonged to 33 people with no evidence of any of the indicated infections.

Table 1. Characteristics of blood serum panels based on laboratory tests performed.

Table 1.
Characteristics of blood serum panels based on laboratory tests performed.

Microscopic observation of the reaction between the T. cruzi epimastigotes used as figured antigen for the immunofluorescence microscopy technique with the serum samples of Panel “A”, corresponding to persons with Leishmania spp. infection (Figure 1 and Table 2), shows the presence of an exclusively nuclear fluorescence pattern that is visualised as internal fluorescence radiating towards the periphery.

Figure 1
Nuclear fluorescence pattern gives the T. cruzi epimastigotes (used as a figured antigen)a marked fluorescence intensity that is seen as small bulbs with green fluorescent illumination in the centre and irradiation towards the periphery. The nuclear fluorescence pattern corresponds to samples from individuals identified as Leishmania spp. infection (panel A).

Table 2.
Serum samples according to the fluorescence pattern they produce with Trypanosoma cruzi epimastigotes. Data expressed in frequency (%).

Panel “B” corresponding to individuals identified with mixed infection by Leishmania spp and T. cruzi, observed by fluorescence microscopy, showed a pattern of nuclear and membrane fluorescence with different degrees of intensity (Figure 2 and Table 2).

Figure 2.
Core/membrane fluorescence pattern gives the T. cruzi epimastigotes used as a figured antigen a marked fluorescence intensity that is seen as small bulbs with green fluorescent illumination. The core/membrane fluorescence pattern corresponds to samples from individuals identified as coinfected with Leishmania spp and Trypanosoma cruzi. (Panel B).

The behaviour of the samples in panel “C”, from individuals identified as T. cruzi infection, showed a membrane fluorescence pattern exclusively with intensity of mostly three crosses (Figure 3 and Table 2).

Figure 3.
Membrane fluorescence patterns give the T. cruzi epimastigotes (used as a figured antigen) a peripheral fluorescence intensity that defines the outline of the parasites. The membrane fluorescence pattern corresponds to samples from individuals identified as Trypanosoma cruzi infection. (Panel C).

f panel “D”, 24% of the samples showed nuclear fluorescence, corresponding to individuals without either of the two infections studied and with permanent residence in the tropical area. (Table 2).

Analysis of samples with no evidence of T cruzi or Leishmania spp infections, grouped according to whether they corresponded to people living in the tropical area (TA) or peri-urban area of the city of Cochabamba (PA), showed absence of membrane (M0) and nuclear (N0) fluorescence in 38% of the TA samples and in 100% of the PA samples. The presence of nuclear fluorescence with intensity one cross (N1) was observed in 62% of the TA samples (Figure 4).

Figure 4
. Frequency of serum samples according to the fluorescence pattern produced by the reaction of fluorochrome-labelled antibodies reacting with Trypanosoma cruzi epimastigotes, from people without evidence of any of the infections evaluated (Leishmania spp and T. cruzi). AT= panel of serum samples from people living in tropical areas (n= 13); AP= panel of serum samples from people living in the peri-urban area of the city of Cochabamba (n=20).

Discussion

Leishmaniasis and Chagas disease are widely distributed in both rural and tropical areas of Latin America. Both are considered by the WHO as tropical diseases of major importance, within the “Neglected or Forgotten Diseases”23. These two diseases are transmitted by different species of protozoa of the order Kinetoplastidae,^r22,25.

Bolivia has been mainly characterised by high rates of mucocutaneous leishmaniasis (MCL) and cutaneous leishmaniasis (CL)4. The increase in cases of leishmaniasis in recent years is mainly attributed to new human settlements due to population migration, mainly from Chagas disease endemic areas to tropical regionss^5,6, which produces changes in the behaviour of the condition due to the coexistence of both pathologies; this is the case in the tropical region of Cochabamba. Hence the importance of detecting both illnesses in areas where they coexist, due to the negative repercussions this could have on the initiation of treatment for leishmaniasis with N-methylglumine antimoniate (Glucantime®), since one of the adverse effects of this first-line drug is cardiotoxicity²⁶.

The immunological diagnosis of Leishmaniasis and Chagas disease presents problems regarding cross-reactions with different species of Leishmania spp and Trypanosoma rangeli^10,12,27especially in co-endemic areas, For this reason, conventional immunofluorescence assays frequently encounter this challenge, given the type of antigen used when detecting anti-T.cruzi antibodies in people co-infected with both trypanozomatids.^10,11,27,28. In this study, in order to determine the differential diagnosis between Leishmaniasis and Chagas disease, T. cruzi epimastigotes were used as antigens14and as shown in Figures 1 and 2, a nuclear fluorescence pattern was observed with the serum corresponding to people with leishmaniasis (panel A), while for mixed infections a nuclear and peripheral fluorescence pattern was observed (panel B); on the other hand, a peripheral pattern, i.e. fluorescence at the membrane level, was observed with the serum corresponding to people diagnosed with Chagas disease (panel C) (Figure 3), which is consistent with the results of a previous study^14,29,30.

On the other hand, when identifying the samples from the tropical area (AT) or the peri-urban area of Cochabamba (AP) without evidence of either of the two conditions (panel D), the presence of nuclear fluorescence with an intensity of one cross (N1) was observed in 8/13 (62%) of the samples from individuals residing in the tropical area (Figure 4), an aspect that was not observed in the serum samples from the residents of the peri-urban area. The presence of fluorescence in this population group from the tropics could be due to the fact that the immune system of the individuals residing in the tropical area promoted both direct and indirect elimination by phagocytosis of the aggressor microorganism, subsequently developing memory antibodies that were detected by immunofluorescence, which could be one of the reasons why these individuals did not present visible clinical lesions. Therefore, factors such as the species and virulence of Leishmania together with the immune and nutritional response of the host could be responsible for these results.

Immunofluorescence (IF) with antigens from T. cruzi epimastigotes has proven useful in differentiating between Chagas disease, Leishmaniasis and/or mixed infections by both parasites in tropical areas where the two coexist as a result of people migrating from Chagas-endemic areas. Therefore, this technique, with emphasis on microscopic observation of immunofluorescence patterns, could be of interest as well as being technically and economically feasible as an alternative to conventional tests. Acknowledgements To Dr. MC Torrico and Lic. Amilcar Flores for their collaboration in the development of this work. Conflict of interest: he authors declare that there is no conflict of interest.

References

1.- Perez-Molina JA, Molina I. Chagas disease. Lancet. 2018; 391:82–94. doi.:0.1016/S0140-6736(17)31612-4. [ Links ]

2.- World Health Organization. Global health estimates 2016 summary tables: DALYs by cause, age and sex, by WHO region, 2000 –2016. World Health Organization, Geneva, Switzerland. 2018. https://www.who.int/healthinfo/global_burden_disease/estimates/en/index1.html. consultado: enero 2020.

3.- Yager JE , Lozano Beltran DF , Torrico F , Gilman H , Bern C. Prevalence of Chagas heart disease in a region endemic for Trypanosoma cruzi: evidence from a central Bolivian community. Glob Heart. 2015; 10(3):145-50. doi: 10.1016/j.gheart.2015.07.002. [ Links ]

4.- Briceño-León R. La enfermedad de Chagas en las Américas: una perspectiva de ecosalud. Cad Saúde Pública. 2009; 25 (1): S71-82. [ Links ]

5.- Albarracin-Veizaga H, Carvalho ME , Nas-cimento EMM, Rodrigues VLCC, Casanova C, Barata JMS. Chagas disease in an area of recent occupation in Cochabamba, Bolivia . Rev Saúde Pública. 1999; 33(3): 230 [ Links ]

6.- Aguilar HM, Abad-Franch F, Pinto-Diaz JC, Veríssimo-Junqueira AC, Rodriguez-Coura J. Chagas disease in the amazons region; Mem. Inst Oswaldo Cruz 2007; 102 (Suppl 1): 31.

7.- Maita Garcia X., Miranda Gutiérrez C., Marañon Mendoza L.C., Carvajal Yañez N., Santander López A., Características Epidemiológicas de la Leishmaniasis en el Departamento de Cochabamba Durante el Periodo 2002-2010. Rev Cient Cienc Méd. 2011: 14 (2).

8.- Pérez León J.L., Kindelán Mercerón F.M., García QuintanaY. Jorge Felix Prat Ricardo J.F., Leishmaniosis Cutánea en un Adulto Mayor. MEDISAN Vol.19 no.9 Santiago de Cuba set.-set. 2015.

9.- Sánchez-Saldaña L., Sáenz-Anduaga E.,Pancorbo-Mendoza J., Zegarra-Del-CarpioR., Garcés-Velasco N., Regis-Roggero A. Leishmaniasis .Dermatología Peruana 2004; vol 14: No 2-82

10.- Bastrenta B., Mita N., Buitrago R., F Vargas F., Flores M.,M Machane M., Yacsik N., Torrez M., Le Pont F., Brenière F. Infecciones humanas mixtas de Leishmania spp. y Leishmani a- Trypanosoma cruzi en un área subandina boliviana: identificación por reacción en cadena de la polimerasa / hibridación e isoenzima. Mem. Inst. Oswaldo Cruz vol.98 no.2 Río de Janeiro marzo de 2003.

11.- Gil J., Cimino, Ines R., lopez Quiroga I., Cajal S., Acosta N., Juarez M., Zacca R., Orellana V., krolewiecki A., Diosque P., Nasser J. Reactividad Del Antigeno GST-SAPA De Trypanosoma cruzi Frente a Sueros De Pacientes Con Enfermedad De Chagas y Leishmaniasis. MEDICINA (Buenos Aires) 2011; 71: 113-119 [ Links ]

12.-Passos VMA, Volpini AC, Braga EM, PAF Lacerda PAF, Ouaissi A, Lima-Martins MV, Krettli AU. Serodiagnóstico diferencial de infecciones humanas causadas por Trypanosoma cruzi y Leishmania spp. Uso de ELISA con un antígeno recombinante (rTc24). Mem. Inst. Oswaldo Cruz Vol. 92 (6): 791-793. Dec. 1997.

13.-Delmans F. M Ch., Postigo J. , Mita Mendoza N., Cruz I., Alvar Ezquerra J., B. Bastrenta. Leishmaniasis visceral subclínica en 123 individuos de un cantón de la provincia Caranavi-La Paz Rev. Soc. Bol. Ped. 2002; 41 (2): 61-66. [ Links ]

14.- Frank FM, Fernández MM, Taranto NJ, Cajal SP, Margani RA, Castro E, Thomaz-Soccol V, Malchiodi EL. Characterization of human infection by Leishmania spp. in the Northwest of Argentina: immune response, double infection with Trypanosoma cruzi and species of Leishmania involved. Parasitol. 2003; 126(1), 31–39. doi.: 10.1017/S0031182002002585 [ Links ]

15.- Romero Peñuela M.H., Sánchez Valencia J.A. Uso de Antígenos Recombinantes para la Evaluación Serológica de Leishmaniasis Visceral y Tripanosomiasis Canina. Biosalud, Volumen 8, enero - diciembre, 2009. págs. 77 – 83.

16.- Vásquez HuertaL., Ruelas Llerena N.,Córdova Benzaquen E. Patrones de coloración en la inmunofluorescencia indirecta y su utilidad en el diagnóstico de leishmaniasis tegumentaria y enfermedad de Chagas Acta méd. peruana v.28 n.1 Lima ene./mar. 2011.

17.- Gomes Y. M. PCR y serodiagnóstico en la enfermedad de Chagas crónica: avances biotecnológicos. Apl Biochem Biotechnol.1997; 66 (1):107- 119. [ Links ]

18.- Caballero ZC, Sousa OE, Marques WP, Saez-Alquezar A, Umezawa ES. Evaluation of serologi-cal tests to identify Trypanosoma cruzi infection in humans and determine cross-reactivity with Trypanosoma rangeli and Leishmania spp. Clin Vaccine Immunol 2007; 14(8): 1045-9. [ Links ]

19.-Wendel S, Gonzaga A. La enfermedad de Chagas y la transfusión de sangre: ¿un problema del nuevo universo? Vox Sang. 1993; 64 : 1–12. [ Links ]

20.-Escalante H, Jara C, Davelois K, Iglesias M, Benites A, Espinoza E. Estandarización de la técnica de Western Blot para el diagnóstico específico de la enfermedad de Chagas utilizando antígenos de excreción-secreción de los epimastigotes de Trypanosoma cruzi. Rev Peru Med Exp Salud Pública. 2014;31(4):644-51. [ Links ]

21.- Requena JM, Soto A. Evolutionarily Conserved Proteins as Prominent Immunogens during Leishmania Infections. Parasitology Today 2000;16(6):246-250. [ Links ]

22.-Levin M, Mesri E, Benarous R, Levitos G, Schijman A, Leyati P, Chiale P, Ruiz A M, Khan A, Rosenbaum M, Torres HN, Segura EL. Identificación de los principales determinantes antigénicos de Trypanosoma cruzi en la enfermedad de Chagas crónica. Am J Trop Med Hyg. 1989; 41 530 538. [ Links ]

23.-World Health Organization. The 17 neglected tropical diseases. Geneva: WHO; 2014, disponible en: http://www.who.int/neglected_diseases/diseases/en/ (consultado 15 de febrero de 2020) [ Links ]

24.- Lake J A, De La Cruz V F, Ferreira P G, et al. Evolution of parasitism: Kinetoplastid protozoan history reconstucted from mitochondrial rRNA gene sequences. Proc Natl Acad Sci 1988; 85: 4779-83 [ Links ]

25.-Vargas-Parada, L. (2010) Kinetoplastids and Their Networks of Interlocked DNA. Educación de la naturaleza 3 ( 9 ) : 63.

26.- Felipe Silva de Freitas P., Rodrigues Borges R.,Hiroshi Sakamoto L.B.,Naves Gonçalves M., Marilene da Silva A., Dutra de Moura F.J., Ribeiro SampaioR.N., Joel Paulo Russomano VeigaJ.P. AVALIAÇÃO DO ELETROCARDIOGRAMA DE PACIENTES COM LEISHMANIOSE TEGUMENTAR AMERICANA TRATADOS COM ANTIMONIAL PENTAVALENTE (GLUCANTIME®) Rev Patol Trop Vol. 43 (4): 405-411, 2014.

27.-Ana de Cássia Vexenat A.,SantanaJ.M., Teixeira A.R.L. Cross-reactivity of antibodies in human infections by the kinetoplastid protozoa Trypanosoma cruzi, Leishmania chagasi and Leishmania (Viannia) braziliensis Rev. Inst. Med. trop. S. Paulo vol.38 no.3 São Paulo May/June 1996

28.-Mita N. Infecciones Mixtas: Identificación de complejos de Leishmania sp y clones de Trypanosoma cruzi por PCR-hibridación en pacientes y mamíferos peridomiciliares de los Yungas, La Paz. Tesis de licenciatura en bioquímica 2001; UMSA.

29.-Chiller TM, Samudio MA, Zoulek G 1990. Reactividad de anticuerpos IgG con antígenos de Trypanosoma cruzi y Leishmania en sueros de pacientes con enfermedad de Chagas y leishmaniasis. Am J Trop Med Hyg 22 : 696-698 30.-Chiaramonte MG, Zwirner NW, Caropresi SL, Taranto NJ, Malchiodi EL 1996. Trypanosoma cruzi y Leishmania spp. Infección mixta humana . Am J Trop Med Hyg 54 : 271-273. 31.-Milena Lenis A. La respuesta celular inmune en la leishmaniasis cutánea americana. Biomedica 1998; 18(4)274-284. [ Links ]

30.-Chiaramonte MG, Zwirner NW, Caropresi SL, Taranto NJ, Malchiodi EL 1996. Trypanosoma cruzi y Leishmania spp. Infección mixta humana . Am J Trop Med Hyg 54 : 271-273.

31.-Milena Lenis A. La respuesta celular inmune en la leishmaniasis cutánea americana. Biomedica 1998; 18(4)274-284. [ Links ]
